Kyo & Kyo PLUS Series

For high-performance DTG printing

Fastest return on investment – with good capacity utilization
Fastest DTG printer on the market
24/7 – High-performance production in shift operation
Integrated OPC-UA interface
Wide range of pallets – including special applications
max. print size 200 x 98 cm
PLUS highlight: Integrated heat presses

Output 12/3 – on dark garments

Print size (40 x 20 cm / ~16 x 8 in)*
Depending on the performance of the operator, material and design.

180*

pieces per hour

Robert Hake, CEO & Founder of MyLocker

“Our company has more than 30 aeoons running 2 shifts/7 days a week. We have tested every commercial DTG machine and aeoon is by far the most scalable solution for POD fulfilment. Their high-definition prints, cost per/print, and up-time reliability are the best in the market. aeoon Technologies blows the competition clean out of water”

DTG printing solutions with outstanding results

High colour brilliance, fine lines, colour gradients, metallic shine, gold shimmer, skin tones, photorealistic images – perfectly printed on various textiles.

Compact PLUS and Kyo PLUS - Integrated Heat Press - aeoon Technologies

PLUS highlight: Integrated heat presses

No press marks
Saving additional work steps
Increased washing resistance of the print because of intermediant and post-pressing

Download folder

Any questions?

We are happy to advise you by phone, email or at our locations in Austria and North America.

Please call me Contact

aeoon Sample Box

You want to see aeoon’s print quality for yourself? Order a FREE samplebox now!

Water based pigment ink

Today, more than ever, DTG printers are focusing on environmental friendliness as customers become more and more conscious of where their product comes from and how it is made.

Learn more

aeoon printing solutions – tailored to your needs

On-demand printing production

Like all our machines, the Kyo and Kyo PLUS can of course also be easily integrated into an automated workflow. No matter how your business grows, aeoon printing systems grow with it! No matter how your business grows, aeoon printing systems grow with it!

More info …

Maintenance and Support

Being a part of the aeoon Family means receiving intense training courses and being able to communicate with our dedicated support team for any questions that may arise, so you are always able to get the absolute best out of our innovative DTG systems.

More info …

Producing sustainably

We take our responsibility towards the environment very seriously and set new standards in many areas. That’s why we work with local suppliers as much as possible, use only GOTS and OEKO-TEX® approved water-based inks and liquids.

More info …

Technical specifications

	Kyo Series	Kyo PLUS Series
Industrial printheads:	Kyocera: 4, 8 or 12	Kyocera: 8 or 12
AHP – Heat Press:	No	Integrated for each printing station; Press size: 40 x 50 cm; ~ 16 x 20 in
Print stations:	2 or 3	3
Color channels:	CMYK (4 Print Heads) CMYK + KYMC, CMYK + 4 Weiß (8 Print Heads) CMYK + KYMC + 4 White, CMYK + 8 White (12 Printheads)	CMYK + KYMC, CMYK + 4 Weiß (8 Print Heads) CMYK + KYMC + 4 White, CMYK + 8 White (12 Printheads)
Max. Print size:	with frame: with 2 or 3 printing stations – 40 x 50 cm; ~16 x 20 in Frameless: with 2 or 3 printing stations – 60 x 90 cm; ~ 24 x 35 in Frameless: with 1 printing stations – 200 x 98 cm; ~ 79 x 39 in	with frame: with 2 or 3 printing stations – 40 x 50 cm; ~16 x 20 in Frameless: with 2 or 3 printing stations – 60 x 90 cm; ~ 24 x 35 in Frameless: with 1 printing stations – 200 x 98 cm; ~ 79 x 39 in
Operating system:	Linux OS	Linux OS
RIP Software:	aeoon RIP Software	aeoon RIP Software
Interface:	OPC-UA and REST	OPC-UA and REST
Ink type:	Water-based pigment ink	Water-based pigment ink
Sales unit:	10l canister	10l canister
Machine size:	410 x 290 x 200 cm / ~161 x 114 x 79 in	410 x 290 x 200 cm / ~161 x 114 x 79 in
Machine weight:	2000 kg / 4409 lb	2450 kg / 5400 lb
Environmental conditions:	Temperature 22 – 24°C; Humidity 50 – 80 % non-condensing	Temperature 22 – 24°C; Humidity 50 – 80 % non-condensing
Electrical connections:	3 x 400/208 V + N + PE, 50 / 60 Hz (+/- 5 %) max. power input: 6,3 kVA	3 x 400/208 V + N + PE, 50 / 60 Hz (+/- 5 %) max. power input: 6,3 kVA + 4,3 kVA
Compressed air:	7 bar – Quality Class 5 (residual oil: 25 mg/mÑ – residual dust: 40 μm / 10 mg/mÑ – residual water + 7 DTP / 7.8 gm/m³) (max. air consumption: 500 l / min)	7 bar – Quality Class 5 (residual oil: 25 mg/mÑ – residual dust: 40 μm / 10 mg/mÑ – residual water + 7 DTP / 7.8 gm/m³) (max. air consumption: 500 l / min)
